Home ProductsPich&Header Connectors

1271 Series
1.27mm Pitch (.050") Header Connectors
Current Rating: 1A AC/DC
Voltage Rating: 250V AC/DC
Contact Resistance: ≤20mΩ

Products Drawing Package Drawing SPEC Crimping Method
4601 Series
2.00mm Pitch (.079＂) Wire To Board Connectors
Current Rating: 2A AC/DC
Voltage Rating: 250V AC/DC
Contact Resistance: ≤20mΩ

Products Drawing SPEC Crimping Method
4601 Series
2.00mm Pitch (.079＂) Wire To Board Connectors
Current Rating: 2A AC/DC
Voltage Rating: 250V AC/DC
Contact Resistance: ≤20mΩ

Products Drawing SPEC Crimping Method
4603 Series
2.00mm Pitch (.079＂) Wire To Board Connectors
Current Rating: 650mA AC/DC
Voltage Rating: 250V AC/DC
Contact Resistance: ≤20mΩ
6501F Series
2.54mm Pitch (.100") Header Connectors
Current Rating: 3A AC/DC
Voltage Rating: 250V AC/DC
Contact Resistance: ≤20mΩ
6501W Series
2.54mm Pitch (.100") Header Connectors
Current Rating: 3A AC/DC
Voltage Rating: 250V AC/DC
Contact Resistance: ≤20mΩ

Products Drawing SPEC
6503 Series
2.54mm Pitch (.100") Header Connectors
Current Rating: 650mA AC/DC
Voltage Rating: 250V AC/DC
Contact Resistance: ≤20mΩ
8672 Series
3.96mm Pitch (.156") Power Connectors
Current Rating: 7A AC/DC
Voltage Rating: 250V AC/DC
Contact Resistance: ≤10mΩ

Products Drawing SPEC Crimping Method
