2564 Series
2.50mm Pitch (.098") Wire To Board Connectors
Current Rating: 3A AC/DC
Voltage Rating: 250V AC/DC
Contact Resistance: ≤20mΩ

Products Drawing SPEC Crimping Method
8821 Series
2.50mm Pitch (.098") Wire To Board Connectors
Current Rating: 3A AC/DC
Voltage Rating: 250V AC/DC
Contact Resistance: ≤10mΩ

Products Drawing SPEC Crimping Method
8854 Series
2.50mm Pitch (.098") Wire To Wire Connectors
Current Rating: 3A AC/DC
Voltage Rating: 250V AC/DC
Contact Resistance: ≤10mΩ

Products Drawing SPEC Crimping Method
2530 Series
2.54mm Pitch (.100") Wire To Board Connectors
Current Rating: 3A AC/DC
Voltage Rating: 250V AC/DC
Contact Resistance: ≤20mΩ

Products Drawing SPEC Crimping Method
2530 Series
2.54mm Pitch (.100") Wire To Board Connectors
Current Rating: 3A AC/DC
Voltage Rating: 250V AC/DC
Contact Resistance: ≤20mΩ

Products Drawing SPEC Crimping Method
9556 Series
2.54mm Pitch (.100") Wire To Board Connectors
Current Rating: 3A AC/DC
Voltage Rating: 250V AC/DC
Contact Resistance: ≤20mΩ

Products Drawing SPEC Crimping Method
3025 Series
3.00mm Pitch (.118") Power Connectors
Current Rating: 5A AC/DC
Voltage Rating: 250V AC/DC
Contact Resistance: ≤10mΩ

Products Drawing SPEC Crimping Method
3025 Double Row Series
3.00mm Pitch (.118") Power Connectors
Current Rating: 5A AC/DC
Voltage Rating: 250V AC/DC
Contact Resistance: ≤10mΩ
