0600 Series0.60mm Pitch (.024＂) IDC Connectors
Current Rating: 0.2A AC/DC
Voltage Rating: 30V AC/DC
Contact Resistance: ≤30mΩ
-
0800H Series0.80mm Pitch (.031") Wire To Board Connectors
Current Rating: 1A AC/DC
Voltage Rating: 50V AC/DC
Contact Resistance: ≤30mΩ
-
0800HI Series0.80mm Pitch (.031") Wire To Board Connectors
Current Rating:0.5A AC/DC
Voltage Rating:30V AC/DC
Contact Resistance:≤20mΩ
-
1002 Double Row Series1.00mm Pitch (.039") Wire To Board Connectors
Current Rating: 1A AC/DC
Voltage Rating: 50V AC/DC
Contact Resistance: ≤20mΩ
-
1002-B Series1.00mm Pitch (.039") Wire To Board Connectors
Current Rating: 1A AC/DC
Voltage Rating: 125V AC/DC
Contact Resistance: ≤20mΩ
-
1004 Series1.00mm Pitch (.039") Wire To Board Connectors
Current Rating: 1A AC/DC
Voltage Rating: 50V AC/DC
Contact Resistance: ≤20mΩ
-
1018 Double Row Series1.00mm Pitch (.039") Wire To Board Connectors
Current Rating: 1A AC/DC
Voltage Rating: 50V AC/DC
Contact Resistance: ≤20mΩ
-
1011 Series1.00mm Pitch (.039") Wire To Board Connectors
Current Rating: 1A AC/DC
Voltage Rating: 50V AC/DC
Contact Resistance: ≤20mΩ
-
1201 Series1.20mm Pitch (.047") Wire To Board Connectors
Current Rating: 2A AC/DC
Voltage Rating: 50V AC/DC
Contact Resistance: ≤10mΩ
-
1224 Series1.20mm Pitch (.039") Wire To Board Connectors
Current Rating: 2A AC/DC
Voltage Rating: 50V AC/DC
Contact Resistance: ≤20mΩ
-
0125 Series1.25mm Pitch (.047") Wire To Board Connectors
Current Rating: 1A AC/DC
Voltage Rating: 50V AC/DC
Contact Resistance: ≤30mΩ
-
1256 Series1.25mm Pitch (.047") Wire To Board Connectors
Current Rating: 1A AC/DC
Voltage Rating: 50V AC/DC
Contact Resistance: ≤30mΩ
-
1251 Series1.25mm Pitch (.047") Wire To Board Connectors
Current Rating: 1A AC/DC
Voltage Rating: 50V AC/DC
Contact Resistance: ≤30mΩ
-
1255 Series1.25mm Pitch (.047") Wire To Board Connectors
Current Rating: 1A AC/DC
Voltage Rating: 200V AC/DC
Contact Resistance: ≤40mΩ
-
1257 Series1.25mm Pitch (.049") Wire To Board Connectors
Current Rating: 1.5A AC/DC
Voltage Rating: 200V AC/DC
Contact Resistance: ≤20mΩ
-
9812 Series1.25mm Pitch (.049") Wire To Board Connectors
Current Rating: 1A AC/DC
Voltage Rating: 150V AC/DC
Contact Resistance: ≤30mΩ
-
9821 Series1.25mm Pitch (.049") Wire To Board Connectors
Current Rating: 1A AC/DC
Voltage Rating: 125V AC/DC
Contact Resistance: ≤20mΩ
-
9862 Series1.25mm Pitch (.049") Wire To Board Connectors
Current Rating: 1A AC/DC
Voltage Rating: 150V AC/DC
Contact Resistance: ≤30mΩ
-
9862-A Series1.25mm Pitch (.049") Wire To Board Connectors
Current Rating: 1A AC/DC
Voltage Rating: 150V AC/DC
Contact Resistance: ≤30mΩ
-
1273 Series1.27mm Pitch (.050") IDC Connectors
Current Rating: 1.2A AC/DC
Voltage Rating: 250V AC/DC
Contact Resistance: ≤10mΩ
